GDS030-300BX
Our air grinder is designed for the manual, peripheral- and transverse grinding with grinding tips and when fabricating with carbide cutters.
Your Advantages: For industrial applications, small and comfortable for good accessibility, highly durable, efficient, ergonomic, simple operation
Well balanced 6-mm collet (Standard Equipment), with supply/exhaust hose.
Objednací číslo
830495A
| Max. power output | 300 W / .40 hp |
|---|---|
| Speed (no load) | 30000 min-1 |
| Weight | 0,4 kg / .88 lbs |
| Drive | vane motor |
| Assortment | Additional Assortment |
| Start | safety lever |
| Design | Basic Design |
| Rotation | right |
| Air consumption (no load) | 0,45 m3/min / 15.89 cfm |
| I.D. of air inlet hose | 6 mm / .24 in |
| Weight (air connection) | 0,32 kg / .71 lbs |
| Max. Ø of grinding tip | 20 mm / .79 in |
| Max. Ø of grinding insert | 6 mm / .24 in |
| Length of supply/exhaust hose | 2/1,25 m / 6.6/4.1 ft |
| Collets - clamping range | 6 [3; 4; 5; 1/8''; 3/16'';1/4''] mm |
| Air connection | Nipple |
| Operating pressure | 6,3 bar / 90 psi |
Standard Equipment
| Collet ø 6 mm |
|
830648 |
|---|---|---|
| Spanner 11 mm |
|
805491 |
| Spanner 6/ 9 mm |
|
830649 |
| Nipple |
|
829220 |
Optional Accessories
| Collet ø 3 mm |
|
830650 |
|---|---|---|
| Collet ø 4 mm |
|
830702 |
| Collet ø 5 mm |
|
830703 |
| Collet ø 1/8'' |
|
830651 |
| Collet ø 1/4'' |
|
830653 |
| Collet ø 3/16'' |
|
830652 |
