GDS030-230VY

Our air grinder is designed for the manual, peripheral- and transverse grinding with grinding tips and when fabricating with carbide cutters. Especially well-suited for the grinding in cavities and hard-to-reach casted areas, the air grinder is equipped with a reduced shank.

The centrifugal speed-regulator reduces a speed overload and assures an economical operation.

Your Advantages: For industrial applications, small and comfortable for good accessibility, highly durable, efficient, ergonomic, simple operation

Well balanced 6-mm collet (Standard Equipment), with supply/exhaust hose.

Noise Level / Vibration

PDF Product Catalog

Objednací číslo

6060847A

Max. power output	300 W / .40 hp
Speed (no load)	23000 min^-1
Weight	0,62 kg / 1.37 lbs
Drive	vane motor
Assortment	Additional Assortment
Start	twist valve
Design	Long design
Rotation	right
Air consumption (no load)	0,35 m³/min / 12.36 cfm
Air consumption (loaded)	0,54 m³/min / 19.07 cfm
I.D. of air inlet hose	8 mm / .31 in
Weight (air connection)	0,5 kg / 1.10 lbs
Max. Ø of grinding tip	20 mm / .79 in
Max. Ø of grinding insert	10 mm / .39 in
Length of supply/exhaust hose	2/1 m / 6.6/3.3 ft
Collets - clamping range	6 [3; 4; 5; 1/8''; 3/16'';1/4''] mm
Air connection	Nipple
Operating pressure	6,3 bar / 90 psi
