GA812-190BX

Our angle grinder with angle gear - for the scrubbing and leveling of cast-iron parts, steel parts, welding seams, non-ferrous metals of all types and rock, as well as for any other fabrication areas, such as the steel construction and container construction, for machine building, in foundries and concrete construction.

The model GA 812-190BX is a more powerful option to the existing grinder Model GA 812-100BX, this tool is suited for the most demanding work in foundries, where the power of 1kW is not enough.

For grinding or when used with cut-off wheels of type 27, 41/42, for the best-possible grinding results even on hard-to-reach areas
The integrated speed regulator holds the speed of the tool constant, even when tool is operated at full load. Low air consumption.

Noise Level / Vibration

PDF Product Catalog

Objednací číslo

6061275A

Max. power output	1900 W / 2.50 hp
Speed (no load)	11900 min^-1
Weight	3,1 kg / 6.83 lbs
Drive	vane motor
Assortment	Standard assortment
Start	safety lever
Rotation	right
Air consumption (no load)	1 m³/min / 35.30 cfm
Air consumption (loaded)	2,2 m³/min / 77.7 cfm
Max. radial speed	80 m/s / 262.5 ft/s
I.D. of air inlet hose	16 mm / .63 in
I.D. of grinding wheel	22,23 mm / .87 in
O.D. of grinding wheel	125 mm / 4.92 in
Max. thickness of grinding wheel	6 mm / .24 in
Max. thickness of cutting-off wheel	2 mm / .08 in
Max. cutting depth	30,5 mm / 1.2 in
Air connection	thread 1/2" female
Spindle thread	M14
Operating pressure	6,3 bar / 90 psi
