DP029-021ZB12Q
Our ergonomic drill for the manual drilling into metal, wood, plastics and other materials. This drill is used for the construction in the aviation- and automotive industry as well as the machine building industry. With pistolgrip design to absorb a higher torque. Without hoses. Our drill is robust, durable, and offers long working lifetimes.
Your advantages: For industrial applications, optimum power-to-weight ratio, ergonomic, simple operation
Objednací číslo
3027101D
| Max. power output | 290 W / .39 hp |
|---|---|
| Speed (no load) | 2100 min-1 |
| Weight | 1 kg / 2.20 lbs |
| Drive | vane motor |
| Assortment | Additional Assortment |
| Start | trigger |
| Rotation | right |
| Air consumption (no load) | 0,35 m3/min / 12.36 cfm |
| Air consumption (loaded) | 0,35 m3/min / 12.36 cfm |
| I.D. of air inlet hose | 6 mm / .24 in |
| Chuck range | 0,5-8 mm |
| Quick change drill chuck | 0-8 mm |
| Taper DIN 238 | B12 |
| Drilling into steel to | 6 mm / .24 in |
| Drilling into alu to | 8 mm / .31 in |
| Air connection | thread 1/4" male |
| Operating pressure | 6,3 bar / 90 psi |
Standard Equipment
| Quick release coupling |
|
804251 |
|---|---|---|
| Nipple |
|
323214 |
| Quick-change drill chuck (capacity 0-8 mm/B12) |
|
805985 |
Optional Accessories
| Drill chuck (capacity 0,8-10 mm/B12) |
|
804650 |
|---|
